PNEUMATIC ISOLATION DEVICE MODEL NP-1 & NP-2

The Pneupod NP-1 and NP-2 are pneumatic isolation devices developed by Pneuance Audio. This product uses air compression as its major isolation method. The rubber diaphragm is a clever way of containing the air and allowing it to isolate in all planes.

The Pneupod devices decouples (or isolates) the attached component from the platform on which it sits. This is in contrast to devices designed to couple to the platform. Spikes (made of aluminum, wood, brass, ceramic, carbon fiber, stainless steel, etc.) tend to rigidly couple the component to its platform.

The NP-1 comes with a bulb type pump and has a maximum weight capacity of 20 lbs. each (80 lbs. for a set of four). The NP-2 comes with a piston pump and has a maximum weight capacity of 40 lbs. (160 lbs. for a set of four).

Specifications & Pricing:

Pneupod NP-1

  • Foot diameter                                                             3 inches (76.2mm)
  • Foot height (deflated)                                              1.25 inches (31.75mm)
  • Foot height (properly inflated)                            1.50 inches (38.1mm)
  • Foot weight                                                                  1/2 lb. (.23 kg)
  • Max weight capacity per foot                                20 lbs. (9 kg)
  • Max weight capacity per set of three                  60 lbs. (27 kg)
  • Max weight capacity per set of four                    80 lbs. (36 kg)
  • Pump Type                                                                    Bulb
  • Price (Box set of three)                                             $  975.00
  • Price (Box set of four)                                               $1,295.00

Pneupod NP-2

  • Foot diameter                                                             3 inches (76.2mm)
  • Foot height (deflated)                                              1.25 inches (31.75mm)
  • Foot height (properly inflated)                            1.50 inches (38.1mm)
  • Foot weight                                                                  1/2 lb. (.23 kg)
  • Max weight capacity per foot                                40 lbs. (18 kg)
  • Max weight capacity per set of three                  120 lbs. (54 kg)
  • Max weight capacity per set of four                    160 lbs. (72 kg)
  • Pump Type                                                                    Piston
  • Price (Box set of three)                                             $1,050.00
  • Price (Box set of four)                                               $1,395.00

PNEUPAD Isolation Platform Series

The Pneupad platforms provide a convenient way to use the Pneupods with audio components. The sleek multi-layer structure is both extremely rigid and sonically dead. We start by using materials that are naturally low in resonance. Applying constrained-mode technology yields a platform that does not ring or sustain vibrations. The low level detail and soundstage are enhanced. Both analog and digital components see vast improvements. Available in two sizes (15" x 17" and 17" x 21"). with included user changeable  accent color bands (black, blue & red). Use with the NP-1 or NP-2 depending on weight requirements.

Specifications & Pricing:

Pneupad NP-15X17

  • Dimensions (wide / deep)                                             17 inches (43.2 cm) / 15 inches (38.1 cm)
  • Platform thickness                                                          1 inch (2.5 cm)
  • Weight                                                                                10 lbs. (4.5 kg)
  • Maximum weight capacity with NP-1 / NP-2        70 lbs. (31.8 kg) / 150 lbs. (68 kg)
  • Price                                                                                     $495.00

Pneupad NP-17X21

  • Dimensions (wide / deep)                                             21 inches (53.3 cm) / 17 inches (43.2 cm)
  • Platform thickness                                                          1 inch (2.5 cm)
  • Weight                                                                                15 lbs. (6.8 kg)
  • Maximum weight capacity with NP-1 / NP-2        65 lbs. (29.5 kg) / 145 lbs. (65.8 kg)
  • Price                                                                                     $650.00

See the technology behind the Pneupod...

Pneupod Isolation Device in Action

The Pneupod NP-1 and NP-2 are designed to enhance the performance and sound of virtually any audio product.

Have a look below at the Pneupod device in customers homes.

What our customers have to say

“It not so much the absence of noise, but a difference in the music’s presence in the room that the Pneupod’s bring about.”

“dazzled by the changes in my system’s performance that I immediately ordered two more sets.”

DB, Mexico

“I immediately noticed a blacker background, and well as a focused clarity that had not been there before. I have now lived with this great design for several weeks, and I am totally convinced that the Pneupod air feet are incredible. I liked them so much a bought a set for under my tube phono section.”

BH, Michigan

“Well it has been a month or so and all I can say is WOW!! I decided to put them under my turntable and the difference it made was startling.”

“There are so many isolation devices out there that I have tried that don’t work it is refreshing to find one that does.”

JH, Michigan

Pneuance Audio Products are Proudly Made in the USA
